ER14250 3.6V Li-SOCl₂ Battery | 1/2AA Lithium Thionyl Chloride Battery for IoT, AMR, Industrial Monitoring & Tracking

Product Details

Cylindrical Li-SOCl₂ (Lithium Thionyl Chloride) batteries are primary (non-rechargeable) lithium batteries known for their high energy density, long operating life, and excellent performance in extreme environments. They are widely used in utility metering, tracking systems, industrial IoT, and backup power.

Characteristics

1.High-voltage(3.6V)

2.The specific energy(500wh/kg) and energy

density(1000wh/dm3) are very high

3.The discharge voltage is very stable

4.Wide working temperature range(-40~85℃)

5.Self-discharge is very low,the shelf-life can be more than 10 years

Application

1.Water meter,Gas meter,Ammeter

2.Memory power for man instrument and meter equipment

Available Models & Specifications

Model	Voltage (V)	Capacity (mAh)	Discharge (mA)	End Voltage (V)	Diameter (mm)	Height (mm)	Weight (g)	Temperature (℃)
ER13150	3.6	450	0.5	2	13.5	15	5.5	-40 ~ +85
ER14250	3.6	1200	0.5	2	14.5	25	10	-40 ~ +85
ER14335	3.6	1600	1	2	14.5	33.5	12	-40 ~ +85
ER14505	3.6	2400	2	2	14.5	50.5	19	-40 ~ +85
ER17505	3.6	3200	1	2	17	50.5	26	-40 ~ +85
ER18505	3.6	3600	1	2	18.5	50.5	28	-40 ~ +85
ER26500	3.6	9000	2	2	26.2	50	52	-40 ~ +85
ER34615	3.6	19000	3	2	34.2	61.5	100	-40 ~ +85
ER14250M	3.6	800	2	2	14.5	25.5	11	-40 ~ +85
ER14335M	3.6	1300	2	2	14.5	34.1	13	-40 ~ +85
ER14505M	3.6	2000	1	2	14.5	50.5	20	-40 ~ +85
ER17505M	3.6	2600	4	2	17	50.5	27	-40 ~ +85
ER18505M	3.6	3500	4	2	18.5	50.5	29	-40 ~ +85
ER26500M	3.6	6500	10	2	26.2	50	53	-40 ~ +85
ER34615M	3.6	13000	20	2	34.2	61.5	110	-40 ~ +85
ER14505S	3.6	1500	16	2	15	50.5	20	0 ~ +150
ER26500S	3.6	3500	35	2	26.5	50	55	0 ~ +150
ER17335	3.6	2000	1	2	17	33.5	18.5	-40 ~ +85

Features

· High Voltage

Nominal voltage of 3.6V, among the highest in primary lithium batteries
· Extremely High Energy Density

Both gravimetric and volumetric energy density are outstanding — ideal for ultra-long-term applications
· Ultra-Long Lifespan

Operating life can exceed 10–15 years, perfect for smart meters and remote sensors
· Low Self-Discharge

Typically less than 1% per year, making it ideal for long-term storage and low-duty-cycle devices
· Wide Operating Temperature

Standard range -40°C to +85°C, with high-temperature versions reaching +150°C.
· Primary Cell (Non-Rechargeable)

Designed for one-time, long-duration use; not suitable for recharging
· Industrial-Oriented

Commonly used in utility metering, tracking devices, remote monitoring systems, military electronics, etc.
· High Internal Resistance

Best suited for low continuous current applications; for high pulse needs, pairing with capacitors is recommended
